Norgard’s exceptional consistency makes it an ideal choice for the signal cable market, where high frequencies are increasingly critical. The low dielectric constant (the lowest offered by Norgard Expanded PTFE Film) coupled with consistently long lengths helps to minimize attenuation, enhancing signal quality where other materials fall short. Norgard ensures optimal signal integrity over extended cable lengths while also reducing both the size and weight of the cable.
NORGARD Engineered Films:
NORGARD Extruded PTFE Film:
- Designed for primary insulation of hook-up wires,
jackets and cables - Highest tensile properties in the industry
- Increased wrapping speed during cable production
- Maintains insulation profile integrity and increases
productivity, reducing manufacturing costs
NORGARD Low Density PTFE Film:
- Unsintered and sintered PTFE films
- Highest achievable tensile strength at the lowest
dimensional variation - Low dielectric constants and lowest attenuation
on longest signal cable lengths - Designed for highest frequencies with lowest signal losses
- Longest achievable tape length
- High-end cable impedance control
NORGARD Skived PTFE Film:
- Full density sintered PTFE films
- Widely used as chemical barrier and binding films in
specialty cables for electrical heating devices - Good abrasion resistance and bearing properties
- Ideal for applications requiring flexibility and robust
performance - Available in different compounded or anti-static versions
FOR WIRE AND CABLE INSTALLATION:
NORGARD Composite Polymide Film:
- Excellent dielectric properties
- Withstands high voltage
- Durable
- Good cut-through and abrasion resistance
- Can be used in a wide range of temperatures
- High radiation resistance and low outgassing
NORGARD Fluoropolymer Films & Coated Fabrics:
- PFA, FEP, ETFE, PVDF, MFA and silicone coated fabrics
- Excellent electrical insulation properties
- Heat sealable
- Good resistance against aggressive media
- Widely used as jacket materials
